SYLGARD™ 182

Compare
Applications
Sylgard® 182 is used for General potting and encapsulating applications such as power supplies, connectors, sensors, transformers, amplifiers, relays
Caracteristics
Transparent / Mix ratio 10:1 / Viscosity: 4575 mPa·s / 51 Shore A / Working time: > 8 hrs / 336 hrs at 25°C (77°F) or 75min at 100°C (212°F) or 20 min at 150°C (302°F)
Property
Sylgard 182 is a Two-part silicone dedicated to Electric / Electronic applications / HTV & RTV addition / UL94 V-0 / Very liquid & long working time / Flexible
Dangerous. Observe safety precautions - For professional use only
See the different packaging
Request for quotation
Request for information
Contactez-nous par téléphone au 04 26 680 680

Variations

This product is not available online.Contact us

Caracteristics

Application Methode Automatic, Manual
Curing Time (min) 336.0000 HOUR
Curing Type Room Temperature Curing
Chemistry / Technology Silicon
Dielectric Strength (kV/mm) 18.0000 kV_mm
Brand SYLGARD
Product's associated market Electronics
Color Clear
Hardness 50 Ashore
Electric Properties Electrically Insulating
Number of Component Bi Componant / 2 Parts
Maximum temperature (°C) 200 CELSIUS
Minimum temperature (°C) -45 CELSIUS
Thermal Conductivity (W/m⋅K) 0.2700 WmK
Dynamic Viscosity (25°C) 4575.0000 mPas
