ARALDITE AV4415/HV4416-1

Compare
Applications

Araldite AV4415 is the resin of a pasty twocomponent epoxy adhesive for bonding pipe, the hardener is HV44161 after post curing at temperatures up to ca 150 ° C allows a bonding resistant to temperatures up to 180 ° C and has excellent resistance to common chemicals, Araldite AV4415 / HV4416 allows bonding a wide variety of ferrous metals, aluminum alloy substrates and plastics such as GRE, GRP, the ABS and SMC

Caracteristics

Two-part epoxy adhesive / Ratio 2:1 / Dark gray paste / viscosity at 25 °C : paste / Pot life 90 min / Shear stregth : 22 Mpa

Property

The AV4415 / HV4416-1 withstands temperatures of 180 °C, excellent resistance to most common chemicals , non-flowable paste facilitating application, fill properties, bonding of a wide variety of substrates, postcuring recommended for optimum properties, approved by KIWA for drinking water, approved REIT Europe

Dangerous. Observe safety precautions - For professional use only
See the different packaging
Request for quotation
Request for information
Contactez-nous par téléphone au 04 26 680 680

Variations

This product is not available online.Contact us
Name Code article Price Availability
ARALDITE AV4415/HV4416-1
200 ml Cartridge
HU21541N Contact us

Caracteristics

Young Modulus 5500 GigaPa
Curing Type Room Temperature Curing
Certification / Specification KIWA
Chemistry / Technology Epoxy
Brand ARALDITE
Color Grey
Mix Ratio 2/1
Hardness Class Very Hard (Shore D56 - D100)
Elongation at break (%) 1.0000
Fixture Time 420 MINUTE
Maximum Gap (mm) 10 MILLIMETER
Number of Component Bi Componant / 2 Parts
Shear Strength (MPa) 22 MegaPa
Maximum temperature (°C) 180 CELSIUS
Minimum temperature (°C) -55 CELSIUS
Glass transition (Tg) (°C) 135 CELSIUS
Dynamic Viscosity (25°C) 150000 mPas
