ELECTROLUBE UR5547

42.22145.64

Compare
Applications
Polyurethane resin formulated for use in potting or cable jointing applications.
Caracteristics
Two-part / Viscosity: 6000 cPs / 85 Shore A hardness / Temperature range: -40°C to +110°C (-40°F to +230°F) /Thermal conductivity: 0.65 W/mK / 24 hrs at 23°C (73.4°F) or 4 hrs at 60°C (140°F).
Property
Resin / Polyurethane PU / Black / Semi-rigid / Good thermal conductivity / Excellent adhesion.
Dangerous. Observe safety precautions - For professional use only
See the different packaging

Variations

Name Code article Price Availability
ELECTROLUBE UR5547
500 g Can
ELUR5547RP500 Quantity : 1+ €35.18 HT Quantity : 10+ €31.98 HT In stock
ELECTROLUBE UR5547
5 kg Kit
ELUR5547RP05KZ Quantity : 1+ €121.37 HT Quantity : 5+ €115.31 HT In stock
ELECTROLUBE UR5547
25 kg Kit
ELUR5547K25K Contact us

Caracteristics

Application Methode Automatic, Manual
Curing Temperature (°C) 23 CELSIUS
Curing Time (min) 24 HOUR
Curing Type Room Temperature Curing
Chemistry / Technology Polyurethane
25°C Gel Time 50 MINUTE
Dielectric Strength (kV/mm) 14 kV_mm
Brand ELECTROLUBE
Product's associated market Electronics
Color Black
Hardness Class Medium Hard (Shore A61 - A80)
Hardness 85 Ashore
Electric Properties Electrically Insulating
Number of Component Bi Componant / 2 Parts
Maximum temperature (°C) 120 CELSIUS
Minimum temperature (°C) -50 CELSIUS
Thermal Conductivity (W/m⋅K) 0.65 WmK
Dynamic Viscosity (25°C) 4000 mPas
