ELECTROLUBE UR5097

31.85652.19

Compare
SKU: ELUR50970
Applications
Polyurethane resin specially engineered for encapsulating and potting electrical and electronic devices operating in harsh conditions such as marine, tropical and automotive environments.
Caracteristiques
Two-part / Viscosity: 6000 cPs / 85 Shore A hardness / Temperature range: -40°C to +110°C (-40°F to +230°F) /Thermal conductivity: 0.65 W/m K / 24 hrs at 23°C (73.4°F) or 4 hrs at 60°C (140°F)
Propriété
Resin / Polyurethane PU / Black / Adhesive/ Water resistant / UL94V-0 / Good thermal conductivity
Dangereux. Respecter les précautions d'emplois
See the different packaging

Variations

This product is not available online.Contact us
Name Price Availability Security form
ELECTROLUBE UR5097 ( 5 kg Kit) Contact us TéléchargerDownload the technical datasheet
ELECTROLUBE UR5097 ( 25 kg Kit) Quantity : 1+ €543.49 HT Quantity : 5+ €516.32 HT Contact us TéléchargerDownload the technical datasheet
ELECTROLUBE UR5097 ( 250 gr Bag) Quantity : 1+ €26.54 HT Quantity : 10+ €24.11 HT Contact us TéléchargerDownload the technical datasheet

Caracteristics

Brand ELECTROLUBE
Product's associated market Electronics
Application Methode Automatic, Manual
Curing Type Room Temperature Curing
Certification / Specification UL 94 V0
Chemistry / Technology Polyurethane
Color Black
Hardness Class Hard (Shore A81 - A100 / Shore D35 - D55)
Hardness 85 Ashore
Electric Properties Electrically Insulating
Number of Component Bi Componant / 2 Parts
Price Unit Pieces
Total Shelf Life 360 DAY
Maximum temperature (°C) 110 CELSIUS
Minimum temperature (°C) -40 CELSIUS
Thermal Conductivity 0.6500 WmK
Viscosity (25°C) 6000.0000 mPas
