Caracteristics
Certification / Specification | BMS 5-28, Type 14, Class 1, REV AN |
---|---|
Chemistry / Technology | Epoxy |
Brand | EPOCAST |
Color | Brown |
Compression Strength (MPa) | 100 MegaPa |
Number of Component | Mono Componant / 1 Part |
Epocast® 1614-A1 is a low-density, one-component structural syntactic epoxy specifically formulated to meet the demanding requirements of the aerospace industry. Supplied frozen and ready for use after thawing, it offers excellent compressive strength (up to 100 MPa) and outstanding thermal stability up to 177 °C (350°F). Qualified to BMS 5-28 Type 14, it is ideally suited for honeycomb composite structures where lightweight performance, durability, and mechanical integrity are critical. Its technical properties make it a reliable solution for:
Filling honeycomb core structures
Reinforcing sandwich panel edges
Potting inserts and fasteners in composite assemblies
Bonding lightweight components exposed to high mechanical stress
Applications requiring high service temperatures (up to 177 °C)
Integration into aerospace manufacturing processes meeting BMS 5-28 standards
One-component syntactic epoxy (supplied frozen, ready to use after thawing)
Low density: ideal for weight-sensitive applications
High compressive strength: up to 14,500 psi (100 MPa)
Excellent thermal resistance: withstands service temperatures up to 177 °C (350°F)
Good extrudability after thawing for easy application
Complies with aerospace standard: BMS 5-28, Type 14, Classes 1 & 2
Flame retardant: self-extinguishing in horizontal position
Name | Code article | Price | Availability | |||||
---|---|---|---|---|---|---|---|---|
Certification / Specification | BMS 5-28, Type 14, Class 1, REV AN |
---|---|
Chemistry / Technology | Epoxy |
Brand | EPOCAST |
Color | Brown |
Compression Strength (MPa) | 100 MegaPa |
Number of Component | Mono Componant / 1 Part |
