EPOCAST 1628 A/B – BMS 5-28 TY 28 REV AN –

Compare
Applications

Epocast® 1628 A/B is a two-component syntactic epoxy featuring ultra-low density and self-extinguishing properties, specially designed for reinforcing edges and filling honeycomb core structures in composite sandwich assemblies. Qualified to BMS 5-28, Type 28, this lightweight compound is supplied as a non-slumping paste, easy to apply with a spatula or trowel, offering excellent workability and handling.

Once cured, the material can be easily sanded or machined, making it ideal for finishing operations in aerospace production or repair environments.

Typical applications include:

  • Edge reinforcement of honeycomb panels

  • Filling of honeycomb cells in sandwich constructions

  • Bonding composite structures requiring weight savings without compromising strength

  • Aerospace applications conforming to BMS 5-28, Type 28

Caracteristics
    • Color (mixed system): Pale yellow
    • Density (mixed system): 500 kg/m³
    • Viscosity at 25 °C: Non-slump paste
    • Working time at 25 °C (60g batch): Approximately 65 minutes
    • Mix ratio (by weight): 100:25 (resin : hardener)
    • Shelf life (unopened): 6 months at 25 °C
    • Compressive strength (25 °C): 19.3 MPa
    • Compressive modulus (25 °C): 1.6 GPa
    • Property
    • Extremely low density: ideal for aerospace weight-saving designs
    • User-friendly application: extrudable paste, easy to spread or trowel
    • Convenient working time: ~65 minutes for operational flexibility
    • Excellent mechanical performance after curing
    • Self-extinguishing: meets stringent fire safety requirements
    • Easily sandable and machinable for precise finishing
    • Dangerous. Observe safety precautions - For professional use only
    See the different packaging
    Request for quotation
    Request for information
    Contactez-nous par téléphone au 04 26 680 680

    Variations

    This product is not available online.Contact us
    Name Code article Price Availability
    EPOCAST 1628 A/B - BMS 5-28 TY 28 REV AN -
    Kit 5 lb
    		HU5190 Contact us

    Caracteristics

    Viscosity Class Pasty / Putty
    Young Modulus 1.6 GigaPa
    Certification / Specification BMS 5-28, Type 28, BMS 5-28, Type 28, REV AN
    Density 500 kg_m3
    Chemistry / Technology Epoxy
    Brand EPOCAST
    Color Pale Yellow
    Compression Strength (MPa) 19.3 MegaPa
    Mix Ratio 100/25
    Number of Component Bi Componant / 2 Parts
