OBO-PASTE 4503-1 RESIN

Compare
Applications

The OBO-PASTE 4503-1 RESIN is based on a modeling paste, brown epoxy paste (after mixing) medium density for machine application, production models and molds

Caracteristics
Colour : paste brown / density 0.7-0.8 g/cm3 / Pot life : 15 min / Machinable after 1 day / max thickness of layers 40 mm / Hardness 55-60 Shore D / flexural strength 11 MPa / mixing ratio : 1: 1
Property
The OBO-PASTE 4503-1 RESIN is a modeling paste for the rapid construction of models with automatic machine high efficiency, layer 40mm thick in one application, low exothermic, virtually odorless during application and machining, dimensional stability
Dangerous. Observe safety precautions - For professional use only
See the different packaging
Request for quotation
Request for information
Contactez-nous par téléphone au 04 26 680 680

Variations

This product is not available online.Contact us
Name Code article Price Availability
OBO-PASTE 4503-1 RESIN
32 kg Pot
OB5041 Contact us
OBO-PASTE 4503-1 RESIN
130 kg Drum
OB1207 Contact us

Caracteristics

Viscosity Class Pasty / Putty
Application Methode Dispensing
Curing Type Room Temperature Curing
Density 750 kg_m3
Chemistry / Technology Epoxy
Brand OBOMODULAN
Color Brown
Compression Strength (MPa) 11.5 MegaPa
Hardness Class Very Hard (Shore D56 - D100)
Hardness 60 Dshore
HDT - Heat Distorsion temperature 55 CELSIUS
Flexural Modulus 11 MegaPa
Maximum Thickness 40 MILLIMETER
Multi parts product type Resin
Mold and Molding - Reinforcement / Filler mineral-en_us
1000 ml Pot-Life 15 MINUTE
Number of Component Bi Componant / 2 Parts
Glass transition (Tg) (°C) 55 CELSIUS
