PERMABOND UV683

Compare
SKU: PEUV68300
Applications
Tackfree UV curing coating, low viscosity for PCB protection or potting
Caracteristiques
One-part / Viscosity 1,500 mPa,s / Fixure time (UV) : 4 seconds / Tensile strength 11 Mpa / Hardness Shore D 60 / Temperature : -50 à +120°C
Propriété
Acrylic coating, instant curing by UV mechanism, crystal clear
Dangereux. Respecter les précautions d'emplois
See the different packaging

Variations

This product is not available online.Contact us
Name Price Availability Security form
PERMABOND UV683 ( 50 ml Bottle) Contact us TéléchargerDownload the technical datasheet
PERMABOND UV683 ( 250 ml Bottle) Contact us TéléchargerDownload the technical datasheet
PERMABOND UV683 ( 1 L Bottle) Contact us TéléchargerDownload the technical datasheet

Caracteristics

Brand PERMABOND
Chemistry / Technology UV Acrylic
Color Clear
Hardness Class Very Hard (Shore D56 - D100)
Hardness 60 Dshore
Elongation at break (%) 75.0000
Fixture Time (min) 7 SECOND
Maximum Gap (mm) 0 MILLIMETER
Total Shelf Life 360 DAY
Maximum temperature (°C) 120 CELSIUS
Minimum temperature (°C) -55 CELSIUS
Tensile Strength 14.0000 MegaPa
Viscosity (25°C) 1500 mPas
