SYLGARD™ 160

Compare
Applications
Sylgard® 160 is used for General encapsulating or potting applications such as power supplies, connectors, sensors, transformers, amplifiers, relays.
Caracteristics
Dark gray / Mix ratio 1:1 / Viscosity: 6025 mPa·s / 56 Shore A / Working time: 25 min / 24 hrs at 25°C (77°F) or 4 min at 100°C (212°F)
Property
Sylgard 160 is a Two-part silicone dedicated to Electric / Electronic applications / HTV & RTV addition / UL 94 V-0 / Good thermal conductivity.
Dangerous. Observe safety precautions - For professional use only
See the different packaging

Variations

This product is not available online.Contact us
Name Code article Price Availability
SYLGARD™ 160
24,9 kg Drum
DE160A249 Contact us
SYLGARD™ 160
226,7 kg Drum
DE160A-226 Contact us

Caracteristics

Application Methode Automatic, Manual
Curing Temperature (°C) 25 CELSIUS
Curing Type Room Temperature Curing
Chemistry / Technology Silicon
Dielectric Strength (kV/mm) 19 kV_mm
Brand SYLGARD
Product's associated market Electronics
Color Grey
Hardness 56 Ashore
Electric Properties Electrically Insulating
Number of Component Bi Componant / 2 Parts
Maximum temperature (°C) 200 CELSIUS
Minimum temperature (°C) -45 CELSIUS
Thermal Conductivity (W/m⋅K) 0.58 WmK
Dynamic Viscosity (25°C) 6025 mPas
