SYSTEM: ARATHANE CW5631 / ARATHANE HY 5610

Compare
Applications

Two component polyurethane casting and impregnation system for high temperature applications. Specifically designed for encapsulation applications of transformers, capacitors and electrical devices operating in potentially explosive environments.

Caracteristics

Two component PU / Viscosity of the mixture at 25°C: 3000 mPa.s / Shore hardness D80 / Thermal conductivity: 0.6 W/m.K / Dielectric strength 29 kV/mm / Class F (155°C)


Property

High thermal resistance

Excellent flow properties

Good thermal conductivity

Non-abrasive casting system

Good thermal shock resistance

Dangerous. Observe safety precautions - For professional use only
See the different packaging
Request for quotation
Request for information
Contactez-nous par téléphone au 04 26 680 680

Produits complémentaire

Caracteristics

Curing Temperature (°C) 23 CELSIUS
Curing Time (min) 24 HOUR
Curing Type Room Temperature Curing
Chemistry / Technology Polyurethane
25°C Gel Time 60 MINUTE
Dielectric Strength (kV/mm) 29 kV_mm
Brand ARATHANE
Color Black
Hardness Class Very Hard (Shore D56 - D100)
Hardness 80 Dshore
Electric Properties Electrically Insulating
Multi parts product type system / Multiparts
Number of Component Bi Componant / 2 Parts
Maximum temperature (°C) 155 CELSIUS
Minimum temperature (°C) -40 CELSIUS
Thermal Conductivity (W/m⋅K) 0.6 WmK
Dynamic Viscosity (25°C) 3000 mPas
